SIP to SIP Call Flow Explained: Practical Guide for Developers (2025)

A comprehensive developer guide to SIP to SIP call flow in 2025, covering SIP signaling, message flows, troubleshooting, code examples, and VoIP optimization.

Introduction to SIP to SIP Call Flow

Session Initiation Protocol (SIP) has been the backbone of modern VoIP (Voice over Internet Protocol) telephony for decades. As organizations continue to migrate voice communications to IP-based systems in 2025, understanding how SIP manages the entire lifecycle of a call is critical for developers, network engineers, and IT professionals. The SIP to SIP call flow refers to the specific sequence of messages exchanged between SIP endpoints (like softphones, PBXs, or gateways) to establish, manage, and terminate calls. Mastery of SIP signaling not only enables effective troubleshooting but also ensures high call quality, robust integrations, and efficient scaling of telephony services.
This guide unpacks the essentials of SIP to SIP call flow, dives deep into key SIP messages, explores advanced call scenarios, and offers practical code, diagrams, and tool-based strategies for call flow analysis and optimization.

Fundamentals of SIP Signaling

SIP is an application-layer signaling protocol designed for initiating, maintaining, and terminating real-time sessions across IP networks. Its simplicity and extensibility make it ideal for VoIP, video calls, presence, and instant messaging.
Key SIP Requests:
  • INVITE: Begins a call session.
  • ACK: Confirms successful session establishment.
  • BYE: Ends a call.
  • CANCEL: Cancels a pending call setup.
  • REGISTER: Registers a user agent with a SIP server.
  • OPTIONS: Queries capabilities of a remote endpoint.
SIP Responses: Responses are categorized by classes:
  • 1xx (Provisional): E.g., 100 Trying, 180 Ringing (call is being alerted)
  • 2xx (Success): E.g., 200 OK (request succeeded)
  • 3xx (Redirection): Call forwarded
  • 4xx (Client Error): E.g., 404 Not Found
  • 5xx (Server Error): E.g., 500 Server Internal Error
  • 6xx (Global Failure): E.g., 603 Decline
Role of SDP in SIP SDP (Session Description Protocol) is usually embedded in SIP messages (e.g., INVITE, 200 OK) to negotiate media parameters: codecs, ports, and protocols. This enables endpoints to agree on how voice (RTP) or video streams will be exchanged.

Detailed SIP to SIP Call Flow Process

A typical SIP to SIP call flow involves a sequence of signaling messages and media negotiation. Let's break it down step by step:

1. Call Initiation (INVITE)

The calling party (User Agent Client, UAC) sends an INVITE request to the called party (User Agent Server, UAS) or via intermediate SIP servers.

2. Session Setup

  • 100 Trying: Indicates the request is being processed.
  • 180 Ringing: The called endpoint is being alerted.
  • 200 OK: The call has been accepted, including SDP for media negotiation.
  • ACK: The caller confirms receipt of 200 OK.

3. Media Negotiation and RTP Establishment

Once the session is confirmed, endpoints exchange RTP (Real-time Transport Protocol) packets carrying audio (and optionally video).

4. Call Teardown (BYE)

When a participant hangs up, a BYE message is sent. The recipient responds with 200 OK, terminating the session and associated RTP streams.

SIP to SIP Call Flow Diagram

This diagram visualizes the signaling path in a basic SIP to SIP call, where a proxy may be involved for routing.

SIP Call Flow Code Example

Here's an annotated example of a SIP call flow with key messages:
1INVITE sip:bob@example.com SIP/2.0
2Via: SIP/2.0/UDP alicepc.example.com;branch=z9hG4bK776asdhds
3From: Alice <sip:alice@example.com>;tag=1928301774
4To: Bob <sip:bob@example.com>
5Call-ID: a84b4c76e66710@alicepc.example.com
6CSeq: 314159 INVITE
7Contact: <sip:alice@alicepc.example.com>
8Content-Type: application/sdp
9Content-Length: ...
10
11// (SDP payload omitted)
12
13180 Ringing
14Via: SIP/2.0/UDP alicepc.example.com;branch=z9hG4bK776asdhds
15From: Alice <sip:alice@example.com>;tag=1928301774
16To: Bob <sip:bob@example.com>;tag=abcdef
17Call-ID: a84b4c76e66710@alicepc.example.com
18CSeq: 314159 INVITE
19
20200 OK
21Via: SIP/2.0/UDP alicepc.example.com;branch=z9hG4bK776asdhds
22From: Alice <sip:alice@example.com>;tag=1928301774
23To: Bob <sip:bob@example.com>;tag=abcdef
24Call-ID: a84b4c76e66710@alicepc.example.com
25CSeq: 314159 INVITE
26Contact: <sip:bob@bobpc.example.com>
27Content-Type: application/sdp
28Content-Length: ...
29
30// (SDP payload omitted)
31
32ACK sip:bob@bobpc.example.com SIP/2.0
33Via: SIP/2.0/UDP alicepc.example.com;branch=z9hG4bK776asdhds
34From: Alice <sip:alice@example.com>;tag=1928301774
35To: Bob <sip:bob@example.com>;tag=abcdef
36Call-ID: a84b4c76e66710@alicepc.example.com
37CSeq: 314159 ACK
38
39BYE sip:bob@bobpc.example.com SIP/2.0
40Via: SIP/2.0/UDP alicepc.example.com;branch=z9hG4bK776asdhds
41From: Alice <sip:alice@example.com>;tag=1928301774
42To: Bob <sip:bob@example.com>;tag=abcdef
43Call-ID: a84b4c76e66710@alicepc.example.com
44CSeq: 314160 BYE
45
46200 OK
47Via: SIP/2.0/UDP alicepc.example.com;branch=z9hG4bK776asdhds
48From: Alice <sip:alice@example.com>;tag=1928301774
49To: Bob <sip:bob@example.com>;tag=abcdef
50Call-ID: a84b4c76e66710@alicepc.example.com
51CSeq: 314160 BYE
52
Each message transitions the call through setup, media negotiation, and teardown. Comments and tags help correlate requests and responses.

Advanced SIP to SIP Call Scenarios

SIP Proxies in Call Flow

SIP proxies route SIP requests and responses, enforce policy, and provide scalability. In a proxy scenario, signaling traverses via one or more intermediaries before reaching the target endpoint.

SIP Gateways

Gateways bridge SIP domains with legacy telephony (e.g., PSTN), translating between SIP and traditional signaling (like ISDN or SS7). The call flow may include protocol conversion steps.

Registration and Authentication

Before making or receiving calls, SIP endpoints often register with a SIP server using the REGISTER method. Authentication ensures only authorized devices/users can place or receive calls.

Call Transfers and Holds

  • Call Transfer: Uses SIP REFER or INVITE with Replaces header to redirect an ongoing call to a new endpoint.
  • Call Hold: Achieved by sending a new SDP offer indicating media is on hold (e.g., a=sendonly or a=inactive).

SIP Trapezoid and Proxy Flow Diagram

Diagram
This SIP trapezoid demonstrates multi-proxy routing, common in business and carrier networks.

Tools for SIP Call Flow Analysis

Understanding and troubleshooting SIP to SIP call flows requires powerful diagnostic tools. Two leading solutions are:

sngrep

sngrep is a command-line utility for capturing and displaying SIP signaling in real time. It visualizes call flows and allows filtering by various parameters.
1sngrep port 5060
2
This command captures SIP traffic on the default SIP port (5060).

Wireshark

Wireshark is a comprehensive network protocol analyzer. It captures and decodes SIP, RTP, and associated protocols, providing deep insight into call flows and media issues.
1wireshark -Y "sip || rtp" -i eth0
2
This command starts Wireshark, filtering for SIP and RTP traffic on interface eth0.

Interpreting SIP Call Flow Diagrams

Both tools can display ladder (sequence) diagrams, mapping the chronological sequence of SIP messages between endpoints. These visuals are invaluable for diagnosing call setup and teardown issues.

Troubleshooting SIP to SIP Call Flow Issues

Common SIP call flow issues include:
  • Registration Failures: Incorrect credentials, server unreachable, NAT/firewall issues.
  • Dropped Calls: Signaling loss, media path failures, session timer expiry.
  • Audio Problems: One-way/no audio (RTP blocked), codec mismatch, SDP negotiation failure.

Debugging Steps

  • Capture SIP and RTP traffic using sngrep or Wireshark.
  • Analyze call flow for missing or malformed messages.
  • Check for error responses (4xx, 5xx, 6xx).
  • Review user agent logs for authentication or NAT traversal issues.

Best Practices

  • Always correlate SIP signaling with RTP streams for end-to-end call quality.
  • Use call logs and analytics for pattern recognition.
  • Regularly test edge cases (e.g., transfers, holds, failovers).

Best Practices for SIP to SIP Call Flow Optimization

  • Ensure Reliable Signaling: Deploy redundant SIP proxies and gateways.
  • Secure Your Calls: Enforce TLS for SIP signaling and SRTP for media. Authenticate all endpoints.
  • Monitor Continuously: Use analytics to detect anomalies, monitor call quality, and preempt issues.
  • Optimize Media Paths: Minimize latency by ensuring direct RTP (media relay only when required).
  • Follow Protocol Standards: Adhere to RFCs for interoperability and future-proofing.

Conclusion

A solid understanding of SIP to SIP call flow is vital for building, maintaining, and troubleshooting VoIP solutions in 2025. Mastery of SIP signaling, combined with the right analysis tools and best practices, ensures high-quality, secure, and reliable IP communications for businesses and service providers alike.
