Building a voice AI agent sounds complex. WebRTC, speech-to-text, text-to-speech, real-time audio pipelines it's a lot to figure out before you even open Xcode.

VideoSDK takes all of that off your plate. You configure your agent from a dashboard, clone a starter app, add your credentials, and run it on your device. That's the whole process. This guide walks you through each step so you can go from zero to a working voice AI iOS app in one sitting.

What You're Building

By the end of this tutorial, you'll have an iOS app where:

  • A user opens the app and joins a meeting room
  • A deployed AI agent automatically joins that same room
  • The user speaks, the agent listens, and responds in real time
  • Live transcription shows up on screen as the conversation happens

Before You Start

Here's what you need before writing a single line of code:

  • A VideoSDK account — Sign up at app.videosdk.live if you haven't already.
  • A deployed AI agent — VideoSDK has a Low-Code Deployment UI in the dashboard. You configure your agent's persona and pipeline (Realtime or Cascading) directly from there, no code required. Once it's deployed, grab your Agent ID and Version ID from the dashboard.
  • Your Auth Token — Head to the API Keys section of the VideoSDK Dashboard. For development, you can generate a temporary token right there. In production, generate this from your own backend to keep your credentials safe.
  • Xcode 16.4 or later — Check your version in Xcode under About Xcode. The app targets iOS 18 or later, so make sure your simulator or physical device is on iOS 18.

Step 1: Create Your Agent

Before touching any code, you need an agent deployed on VideoSDK. This is done entirely from the dashboard, no coding required.

1.1 Build Your Agent

Head to the VideoSDK Dashboard and follow the Build a Custom Voice AI Agent guide. Here you'll set up your agent's persona, give it a name and personality, and choose its pipeline type:

  • Realtime pipeline — lower latency, better for fast back-and-forth conversations
  • Cascading pipeline — more control over each stage (STT, LLM, TTS) separately

You can also test your agent directly from the dashboard before deploying it.

1.2 Deploy Your Agent

Once you're happy with the configuration, hit Deploy. VideoSDK builds and hosts your agent on its Agent Cloud infrastructure.

1.3 Get Your Agent ID and Version ID

You'll need two identifiers to connect your iOS app to the agent:

Agent ID — After creating your agent, open its page and find the JSON editor on the right side. Copy the agentId from there.

Version ID — Click the three dots next to the Deploy button and select "Version History". Each time you deploy, a new version is created. Copy the version ID for the version you want to use. If you skip this, the app will automatically pick the latest deployed version.

Video SDK Image

Keep both of these handy. You'll need them in Step 4 when configuring your credentials.

Step 2: Clone the Starter App

VideoSDK provides a ready-to-go iOS starter app. Clone it and navigate into the project folder:

git clone https://github.com/videosdk-live/agent-starter-app-ios.git
cd agent-starter-ios

Step 3: Open the Project in Xcode

Open the project file in Xcode:

open agent-starter-ios.xcodeproj

Or double-click agent-starter-ios.xcodeproj from Finder. Xcode will load the project and index the files.

Step 4: Set Up Your Credentials

Instead of an .env file, the iOS app uses a Swift constants file. Open agent-starter-ios/Constants/MeetingConfig.swift in Xcode and fill in your values:

AUTH_TOKEN: <VideoSDK authorization token>
AGENT_ID: <The ID of the Agent on VideoSDK>
MEETING_ID: <VideoSDK Meeting ID | Optional>
VERSION_ID: <VideoSDK Agent's Version ID | Optional>

A quick note on each:

  • AUTH_TOKEN — your VideoSDK token from the dashboard
  • AGENT_ID — the ID of the agent you deployed from the dashboard
  • MEETING_ID — optional. If you leave this blank, the app will create a new meeting room automatically
  • VERSION_ID — optional. If you leave this blank, the app will fetch the latest deployed version of your agent

Step 5: Build and Run

Select your target device or simulator from the device picker in Xcode, then click the Run button or press Cmd + R.

Once the app launches, allow microphone access when prompted, and start talking. The app uses VideoSDK's Dispatch API to send your deployed agent into the meeting room. You'll see transcription appear on screen in real time as you speak and as the agent responds.

What's Happening Under the Hood

When the app starts, a few things happen in sequence:

  1. The app calls VideoSDK's API to create (or join) a meeting room
  2. It uses the Dispatch API to summon your deployed agent into that room, passing it the AGENT_ID and VERSION_ID
  3. The agent joins as a participant, listens through the room's audio channel, and responds using its configured pipeline
  4. The SDK streams transcription back to the iOS frontend in real time

You don't manage any of that manually. The SDK and your dashboard-deployed agent handle it.

Real-World Use Cases

Once you have this running, you're one agent config away from building any of these:

  • Customer Support Bots Replace your static FAQ chatbot with a voice-first support agent. Users speak their issue, the agent understands context, and responds instantly.
  • AI Interview Practice Tools Build a mock interview app where the AI agent asks questions, listens to answers, and gives feedback. Great for job seekers, students, or sales training.
  • Voice-Enabled Coding Assistants Let developers describe what they want to build, and the agent helps them think through solutions, hands-free while they're heads-down in their editor.
  • Interactive Learning and Tutoring Build a language learning app, a math tutor, or an onboarding guide that actually talks back. Learners engage better when they can have a real conversation.
  • Accessibility-First Interfaces For users who struggle with keyboards or touchscreens, a voice AI agent makes your product genuinely usable, not just technically compliant.

Troubleshooting

A few things to check if something isn't working:

  • Agent isn't joining the room Double-check your AGENT_ID and VERSION_ID in MeetingConfig.swift. A single wrong character here is the most common culprit. Also verify your VideoSDK token is valid and has the necessary permissions.
  • Audio isn't working Check that the app has microphone permissions on your device. Go to Settings, find the app, and make sure microphone access is enabled.
  • "Failed to connect agent" error Verify your AGENT_ID and VERSION_ID are correct. Open the Xcode debug console and look for network errors, they usually point to exactly what's wrong.

Wrapping Up

Adding a voice AI agent to an iOS app used to mean stitching together STT, TTS, WebRTC, and a custom backend. With VideoSDK, you configure your agent from a dashboard, clone a starter app, fill in a config file, and run it from Xcode.

The Dispatch API does the heavy lifting. Your agent shows up in the room, listens, and responds. You just build the experience around it.

If you haven't deployed your agent yet, start there. The Low-Code Deployment UI on the VideoSDK Dashboard walks you through it without touching code. Once it's deployed, come back here and you'll be live in under 10 minutes.

Ready to build?
