Build a Voice Bot with Twilio: Step-by-Step Guide

1python -m venv venv
2source venv/bin/activate  # On Windows use `venv\Scripts\activate`
3

1pip install videosdk twilio python-dotenv
2

1VIDEOSDK_API_KEY=your_videosdk_api_key
2TWILIO_ACCOUNT_SID=your_twilio_account_sid
3TWILIO_AUTH_TOKEN=your_twilio_auth_token
4

1import asyncio, os
2from videosdk.agents import Agent, AgentSession, CascadingPipeline, JobContext, RoomOptions, WorkerJob, ConversationFlow
3from videosdk.plugins.silero import SileroVAD
4from videosdk.plugins.turn_detector import TurnDetector, pre_download_model
5from videosdk.plugins.deepgram import DeepgramSTT
6from videosdk.plugins.openai import OpenAILLM
7from videosdk.plugins.elevenlabs import ElevenLabsTTS
8from typing import AsyncIterator
9
10# Pre-downloading the Turn Detector model
11pre_download_model()
12
13agent_instructions = "{\n  \"persona\": \"helpful technical assistant\",\n  \"capabilities\": [\n    \"guide users through the process of building a voice bot using Twilio\",\n    \"provide step-by-step instructions for setting up Twilio APIs\",\n    \"assist with troubleshooting common issues during the implementation\",\n    \"offer best practices for optimizing voice bot performance\"\n  ],\n  \"constraints\": [\n    \"you are not a certified Twilio support representative\",\n    \"you must include a disclaimer that users should refer to Twilio's official documentation for detailed technical support\",\n    \"you cannot provide real-time coding assistance or debug code\"\n  ]\n}"
14
15class MyVoiceAgent(Agent):
16    def __init__(self):
17        super().__init__(instructions=agent_instructions)
18    async def on_enter(self): await self.session.say("Hello! How can I help?")
19    async def on_exit(self): await self.session.say("Goodbye!")
20
21async def start_session(context: JobContext):
22    # Create agent and conversation flow
23    agent = MyVoiceAgent()
24    conversation_flow = ConversationFlow(agent)
25
26    # Create pipeline
27    pipeline = CascadingPipeline(
28        stt=DeepgramSTT(model="nova-2", language="en"),
29        llm=OpenAILLM(model="gpt-4o"),
30        tts=ElevenLabsTTS(model="eleven_flash_v2_5"),
31        vad=SileroVAD(threshold=0.35),
32        turn_detector=TurnDetector(threshold=0.8)
33    )
34
35    session = AgentSession(
36        agent=agent,
37        pipeline=pipeline,
38        conversation_flow=conversation_flow
39    )
40
41    try:
42        await context.connect()
43        await session.start()
44        # Keep the session running until manually terminated
45        await asyncio.Event().wait()
46    finally:
47        # Clean up resources when done
48        await session.close()
49        await context.shutdown()
50
51def make_context() -> JobContext:
52    room_options = RoomOptions(
53    #  room_id="YOUR_MEETING_ID",  # Set to join a pre-created room; omit to auto-create
54        name="VideoSDK Cascaded Agent",
55        playground=True
56    )
57
58    return JobContext(room_options=room_options)
59
60if __name__ == "__main__":
61    job = WorkerJob(entrypoint=start_session, jobctx=make_context)
62    job.start()
63

1curl -X POST "https://api.videosdk.live/v1/meetings" \
2-H "Authorization: Bearer YOUR_VIDEOSDK_API_KEY" \
3-H "Content-Type: application/json"
4

1class MyVoiceAgent(Agent):
2    def __init__(self):
3        super().__init__(instructions=agent_instructions)
4    async def on_enter(self): await self.session.say("Hello! How can I help?")
5    async def on_exit(self): await self.session.say("Goodbye!")
6

1pipeline = CascadingPipeline(
2    stt=DeepgramSTT(model="nova-2", language="en"),
3    llm=OpenAILLM(model="gpt-4o"),
4    tts=ElevenLabsTTS(model="eleven_flash_v2_5"),
5    vad=SileroVAD(threshold=0.35),
6    turn_detector=TurnDetector(threshold=0.8)
7)
8

1async def start_session(context: JobContext):
2    # Create agent and conversation flow
3    agent = MyVoiceAgent()
4    conversation_flow = ConversationFlow(agent)
5
6    # Create pipeline
7    pipeline = CascadingPipeline(
8        stt=DeepgramSTT(model="nova-2", language="en"),
9        llm=OpenAILLM(model="gpt-4o"),
10        tts=ElevenLabsTTS(model="eleven_flash_v2_5"),
11        vad=SileroVAD(threshold=0.35),
12        turn_detector=TurnDetector(threshold=0.8)
13    )
14
15    session = AgentSession(
16        agent=agent,
17        pipeline=pipeline,
18        conversation_flow=conversation_flow
19    )
20
21    try:
22        await context.connect()
23        await session.start()
24        # Keep the session running until manually terminated
25        await asyncio.Event().wait()
26    finally:
27        # Clean up resources when done
28        await session.close()
29        await context.shutdown()
30

1def make_context() -> JobContext:
2    room_options = RoomOptions(
3    #  room_id="YOUR_MEETING_ID",  # Set to join a pre-created room; omit to auto-create
4        name="VideoSDK Cascaded Agent",
5        playground=True
6    )
7
8    return JobContext(room_options=room_options)
9

1if __name__ == "__main__":
2    job = WorkerJob(entrypoint=start_session, jobctx=make_context)
3    job.start()
4

1python main.py
2
